SOTA – Homebrew 23cm 12 element Yagi Antenna

Super homebrew work well worth the reblog.

Get out of the Radio Shack and Live Life

Sunday 18 June 2017.  I recently purchased a new 2.5 watt 23 cm transverter from SG-Lab in Sofia Bulgaria. The package includes a 2el HB9VC PCB which has turned out to be a great addition for portable work, particularly from a hilltop with a good uninterrupted view of the horizon.  Today from the summit of Mt Taylor VK1/AC-037 locator QF44MP, I worked Rod VK2TWR in Nimmitabel over 130 km, not bad for 2 watts in to a tiny PCB antenna.

While the PCB antenna is a great addition to the SOTA kit, be it for local summits or perhaps on a long hike 10 km or more, what I really need is an antenna with a fair amount of ‘oomph’ that’s non-techo speak for gain, whilst keeping weight and size or length within reasonable limits.

For SOTA purposes keeping antenna construction as simple as possible is a key attribute to…

View original post 1,301 more words

SOTA – Getting on 1296 MHz with a Transverter

I hope to be on 23 cm myself by the end of 2017. Great stuff!

Get out of the Radio Shack and Live Life

How do you get on 23 cm 1296.2 MHz USB for SOTA activations without forking out loads of dough for an ICOM IC-910 or IC-9100?  Answer a lightweight all mode 2.5 watt 23 cm transverter from Hristiyan LZ5HP in Sofia Bulgaria.  The current unit on offer is version 2.3.

SG-Lab all mode 2.5 watt 23 cm Transverter version 2.3.  The parcel arrived after 13 calendar days between Bulgaria and Canberra Australia, pretty good considering the transition points along the way.

The 23cm transverter’s default configuration is simplex with the local oscillator (LO) set to 1152 MHz.  The unit has internal jumpers to change the LO frequency by +/- 2 MHz, this option permits simplex operation on 1294 MHz FM.  A separate jumper configures the unit for simplex or repeater operation while a fourth jumper configures the repeater offset which in VK is 20 MHz.  We don’t have a 23cm repeater…

View original post 775 more words

Setbacks and progress on the antenna front

IMG_1031

The “offending” mast

Back in January Gary, MM0CUG, visited the QTH to install a mast on the side of our house to support the three antennas I have in mind. For various reasons outside his or my control he was not able to finish the job, so we had the mast up with no antennas.

Gary was scheduled to return to put the antennas on the mast for me, but in the intervening period someone complained to the Planning Department of the local Council. I have spoken to all the obvious neighbours and none has admitted to complaining. I believe all of them, so it is a mystery as to who objected.

One of the planning officers came around, and although many amateurs around here have antennas up without Council approval, I was told that I would have to apply for planning permission, which I have now done. Unfortunately, I must wait up to eight weeks to know whether my application is successful. There is a possibility I will have to take the mast down, although feedback I have received from the Council so far leads me to be cautiously optimistic.

The plan is to have 7 elements LFA Yagi from Innovantennas to 144 MHz, a 13 element from them for 432 MHz, and a 23 element Tonna Yagi for 1296 Mhz. These were the bands on which I was most active over thirty years ago and I hope to make a decent comeback. I am aware that activity is much less than it used to be, but I aim to contribute to a considerable increase.

I just cannot wait to be back doing what I used to. My current restriction to a collinear for 2 metres and 70 cms is very frustrating and I am just not an HF person at heart, though I understand that even if I were, conditions are very poor due to where we are in the Sun’s cycle.

I will be back, by hook or by crook.
